Angular contact ball bearingsStainless Steel Bearings

Construction: Double-row rolling elements; inner and outer rings with dual raceways; fixed contact angle; available in three mounting configurations: back-to-back, face-to-face and in series. Performance: Capable of withstanding radial loads and bidirectional axial loads; superior rigidity and anti-tipping capacity compared to single-row angular contact ball bearings. Applications: High-rigidity, high-precision, heavy-load conditions, such as machine tool spindles, precision gearboxes and high-power motors. Advantages: A single bearing can replace a combination of two single-row bearings, simplifying installation and saving space.


Angular contact ball bearingsStainless Steel Bearings
Angular contact ball bearingsStainless Steel Bearings

Product Parameters

Inquiry Bearing Basic Dimensions (mm) Rated Load (kN) Limiting Speed (r/min) Weight
≈kg
Model d D B C Dynamic C0 Static Limiting
✉️ SS5217-2RS 85 150 49.2 116 110 3600 3.4
✉️ SS5215-2RS 75 130 41.3 93.5 83 4300 1.9
✉️ SS5216-2RS 80 140 44.4 99 93 3800 2.5
✉️ SS5314-2RS 70 150 63.5 159 128 3800 4.9
✉️ SS5313-2RS 65 140 58.7 142 113 4300 3.85
✉️ SS5214-2RS 70 125 39.7 94 82 4500 1.8
✉️ SS5213-2RS 65 120 38.1 76.5 69 4500 1.65
✉️ SS5311-2RS 55 120 49.2 95 73 5000 2.3
✉️ SS5212-2RS 60 110 36.5 69 62 5000 1.35
✉️ SS5312-2RS 60 130 54 125 98.5 4500 3.15
✉️ SS5210-2RS 50 90 30.2 53 43.5 6000 0.67
✉️ SS5310-2RS 50 110 44.4 81.5 61.5 5600 1.95
✉️ SS5211-2RS 55 100 33.3 56 49 5600 0.96
✉️ SS5209-2RS 45 85 30.2 49.5 38 6700 0.62
✉️ SS5309-2RS 45 100 39.7 68.5 51 6000 1.4
✉️ SS5208-2RS 40 80 30.2 44 33.5 7100 0.57
✉️ SS5308-2RS 40 90 36.5 56.5 41 6700 1.05
✉️ SS5207-2RS 35 72 27 39 28.7 8000 0.43
✉️ SS5307-2RS 35 80 34.9 51 36 7500 0.79
✉️ SS5306-2RS 30 72 30.2 40.5 28.1 8500 0.51
