Deep-groove ball bearingsStainless Steel Bearings

Deep groove ball bearings are designed in imperial units (inches), with a structure identical to their metric counterparts. They consist of an inner ring, an outer ring, steel balls and a cage, and are capable of withstanding radial loads as well as a certain degree of bidirectional axial loads. Suitable for use in imperial-standard equipment or for the maintenance of imported machinery, these bearings offer high precision and versatility, and are commonly used in fields such as automated equipment, precision instruments and aerospace components.

Deep-groove ball bearingsStainless Steel Bearings
Deep-groove ball bearingsStainless Steel Bearings

Product Parameters

Inquiry Bearing Basic Dimensions (mm) Rated Load (kN) Limiting Speed (r/min) Weight
≈kg
Model d D B C Dynamic C0 Static Limiting
✉️ SFR10-2RS 15.875 34.925 — 6070 3300 24000 31.8
✉️ SFR8-2RS 12.7 28.575 6.35 5210 2440 30000 22.7
✉️ SFR6-2RS 9.525 22.225 7.142 3350 1410 38000 12.1
✉️ SFR4-2RS 6.35 15.875 4.978 1610 660 45000 4.78
✉️ SFR188-2RS 6.35 12.7 3.175 1080 440 50000 2.49
✉️ SFR3-2RS 4.762 12.7 4.978 1300 485 53000 3.09
✉️ SFR156-2RS 4.762 7.938 2.779 360 149 63000 0.53
✉️ SFR155-2RS 3.967 7.938 2.779 360 149 63000 0.67
✉️ SFR2-2RS 3.175 9.525 3.967 630 218 67000 1.55
✉️ SFR2-6-2RS 3.175 9.525 2.779 640 225 63000 1.25
✉️ SFR10ZZ 15.875 34.925 — 6070 3300 24000 31.8
✉️ SFR8ZZ 12.7 28.575 6.35 5210 2440 30000 22.7
✉️ SFR6ZZ 9.525 22.225 7.142 3350 1410 38000 12.1
✉️ SFR1810ZZ 7.938 12.7 3.967 540 276 48000 1.63
✉️ SFR4ZZ 6.35 15.875 4.978 1610 660 45000 4.78
✉️ SFR188ZZ 6.35 12.7 3.175 1080 440 50000 2.49
✉️ SFR168ZZ 6.35 9.525 3.175 420 204 56000 0.75
✉️ SFR3ZZ 4.762 12.7 4.978 1300 485 53000 3.09
✉️ SFR166ZZ 4.762 9.525 3.175 710 270 60000 0.98
✉️ SFR156ZZ 4.762 7.938 2.779 360 149 63000 0.53
